DENN DPA-240BZ
Public Address 5-Zone Selector Amplifier (Mono 100V)
Key Features
- 5-Zone Selector Amplifier
- Mono 100V Output
- Bluetooth & USB Playback
- FM Tuner
- MIC Priority Function
- Flight Case Ready (Standard 19" Rack)
- 240W Output Power
RM 1540.00
RM 1790.00
Features
Country of Origin
Made in Taiwan
Channel Amplifier
Mono
Parallel Looping
N/A
Bluetooth
Yes
USB
Yes
Tuner FM
Yes
Zone Selector
5-zone selector
Mic Phantom Power (48V)
N/A
Mic Priority
Yes. MIC-1 equipped with mic priority feature
XLR / Phono Jack Input Per Channel
6-channel (5 front input level control, 2 selection switches MIC / PHONO, MIC / AUX)
XLR / Phono Jack Output Per Channel
2-channel AUX, TAPE output
Input Gain Control
Master volume, bass and treble control
Parallel / Mono Selection Switch
N/A
Speaker Output
4Ω, 8Ω, 70V, 100V
Flight Case Mounted
Yes. Standard 19" rack
Height (3U, 2U, 1U)
2U
Circuit Protection
Over temperature, over load, speaker short protection
Specifications
| Output Power | 240 Watt |
|---|---|
| Power Supply | AC 115V / 230V, 50-60HZ, DC 24V |
| Speaker Output | 4Ω, 8Ω, 70V, 100V |
| Line Output | N/A |
| Record Output | 1V / 100Ω |
| Frequence Response | 50Hz-15kHz ± 3dB |
| Input Sensitivity & Impedance | 1/4" Phone Jack (unbalanced) Channel 1-3 (MIC 1-3), 1mV @ 600Ω or PHONO, 2mV @ 50kΩ Channel 4 (MIC 4), 1mV 600Ω or AUX 1, 100mV @ 22kΩ Channel 5 (AUX 2), AUX 3, 100mV @ 10kΩ TAPE out (RCA), AUX out (RCA), 1V |
| Mute Priority | MIC 1, MIC 2 is not affected |
| Voice Priority Mute | N/A |
| Phantom Power Adjustable (48V) | N/A |
| Tone Control | Bass: 100Hz ± 10dB, Treble 10kHz ± 10db |
| Total Harmonic Distortion | <0.1% @ 1kHz, rated power |
| Signal to Noise Ratio | >86dB |
| Indicator | Power On, Level |
| AC Power Consumption | 640 Watts |
| DC Power Consumption | 16A |
| Product Dimension (W x H x D) | 425mm x 88mm x 305mm |
| Packing Dimension (W x H x D) | 485mm x 180mm x 410mm |
| Weight | 10.5kg |
| Ser Per Carton | 2 sets per carton |
